*CALC ERR - Math calculation error encountered (i.e. underflow or overflow result).
Possible causes for the *CALC ERR message include:
A. Resultant value exceeds allowable range (i.e. volume value greater than 999,999,999)
B. Negative volume calculated.
C. Division by zero.
*VCF ERR - VCF parameter (API or TEC) exceeded allowable range for selected volume tables
(6A, 6B, 6C, 6CMOD).
Possible causes for the *VCF ERR message include:
A. Programming errors when entering API or TEC programming parameters. Normally user
entries are checked against allowable limits during program mode. It is still possible to
enter illegal API or TEC values by first selecting an API table with wider limits (6A) and
entering for example an API of 100. Then reselecting a new API table with narrower lim-
its (6B). Unless the API programming screen is reentered, the API value of 100 would not
be rechecked and changed to the current limit for table 6B. This will cause a *VCF ERR
message to be displayed during measurement mode because the API value of 100
exceeds the allowable range for table 6B. See General Software Information section of
this manual for additional information about allowable limits for API tables.
*INIT - Mass stabilization function is initializing.
Possible causes for the *INIT message include:
A. The mass stabilization function has been enabled for the selected tank and the MASSR
(mass reference) has not been updated. This message will clear after the selected tank
has been updated by the scan processor.
*NO REF - Mass stabilization mass reference could not be initialized.
Possible causes for the *NO REF message include:
A. Net mass data not available at time mass stabilization function was enabled due to other
active volume error messages. See related volume error messages in previous section.
*OFF - Mass Stabilization function is disabled.
Error messages for the Side Tank Indicator (STI) interface appear on a separate STI error status
screen. The STI error status screen is only displayed if the STI interface is enabled and error mes-
sages are active or by depressing the “0” key during measurement mode. An example of the STI
error status screen is shown below.
Side Tank Indicator error message example
STI ERROR STATUS
1-*CME 2-*CSE
26
