Feedback Wiring
TB1
1
18
SIG
BAL
RESP
CUR
100% SHIELDED
REFERENCE FREQUENCY
2KHZ 20-25 VP-P
SIN/COS 0-5V MAX RMS
WINDING THERM
SIN
REF
COS
1
2
3
4
5
6
7
8
17
REF
REF GND
SIN
SIN GND
COS
COS GND
THERM SWITCH
THERM GND
SHIELD
NOTE
100% shielded cable is foil and braid. The
pairs do not have to be twisted. The resolver
wiring should not be run adjacent to any non-
shielded high voltage wires, such as the motor
wires (RST). If the wiring cannot be
separated, the RST motor leads should also
be 100% shielded. It is highly recommended
that factory cable sets or wiring be provided.
