4
Specifications
Parameter Specification
Operating Environment:
Temperature
Humidity
0 to 45°C (32 to 113°F) Maximum, Ambient
0 to 95% noncondensing
Input Interface: Analog Signals
Velocity Command Input
TAC Gradient
Differential Input 0 to ±10 Vdc (15 Vdc Max)
3.0 Volts per 1000 rpm (14-bit mode)
.75 Volts per 1000 rpm (12-bit mode)
24 Volt Logic: Velocity/Torque Mode
Enable
Start (option only)
Velocity/Torque Select
Fault Output (Open Collector)
Ready (option only)
Both of the outputs are open collector (30 Vdc max) and can
sink .15 amps when ON.
Fault Protection: Continuous Current
Shorts (Stator)
Feedback Resolver Tracking
Motor Thermal
Electrical Characteristics:
Input Voltage
80 to 260 Vac
45 to 65 Hz
Single Phase
No Isolation Transformer Required
MPA-03SL:
Output:
Input:
3 amps continuous; 6 amps peak; peak ≤ 1 second
PWM frequency 18 kHz
Single phase; 5 amps continuous max
DC Bus is ac line dependent
MPA-06SL:
Output:
Input:
6 amps continuous; 12 amps peak; peak ≤ 1 second
PWM frequency 18 kHz
Single phase, 8 amps continuous max
DC Bus is ac line dependent
Motor/Amplifier Speed and Load
Relationship
The motors maximum speed is
dependent on the bus voltage and
motor KE by the following relationships.
In the Velocity Mode of operation, the
TAC Gradient also would limit the
speed.
(AC Input)/(Motor KE vrms) = Max no load speed.
Max no load speed
*
.75 = Maximum speed at continuous full
load.
10/TAC Gradient = (MAX no load speed)Krpm
Adjustments: 0 - Peak Current Limit (CL)
Response (RESP)
Signal (SIG)
Balance (BAL)
Speed/Torque Regulation: ±5%
Weight: 3 lbs. max
