Item Type of shielding Comments
1 (free end) Shield (A8) On fuel filter
2 (free end) Shield (A7) Above fuel priming pump
3 (free end) Shield (A7) Below fuel priming pump
Driving end A-side
Item Type of shielding Comments
1 (Driving end, A-side) Shield (A5) On air flap
2 (Driving end, A-side) Shield (A4) On brazed-on union
3 (driving end, A-side) Shield (A5) On turbocharger flap
4 (driving end, A-side) Shield (A5) On turbocharger flap
Driving end A-side
