Configuring the 1330 in ASCII Mode
*** PRINTER SETUP ***
401 OPERATOR FORMAT 2 Saved
402 KEY ALARM 0 No Sound
403 ALARM ON ERROR 1 Yes
404 PRNT HEAD STYL 1
405 PRT HD COL SPAC 95
406 RIBBON TYPE 0 Use Sensor
407 RB TRAK SEL ADJ 05
408 MODULE TYPE 0 Use Sensor
409 AUTO EJECT 00
410 AUTO RETURN ADJ 05
411 EJECT ADJUSTMENT 127
412 HORZ OFFSET 14
413 HORZ REGSTRN 127
414 PAPER JAM 1 Enable Sensr
415 PAPER OUT 1 Enable Sensr
416 PAPER SKEW 1 Enable Sensr
** COMMUNICATION **
501 PRINTER EMULTN 1 PROPRINTER
502 BUFFER SIZE 1 2K
503 DC1 / DC3 1 Recognize
504 BAUD RATE 4 ( 9600 )
505 PARITY 2 Even
506 DATA BITS 1 Seven
507 STOP BITS 1 One
508 MODEM CONTROL 1 DCD/DSR Used
509 HANDSHAKING 1 XON/XOFF
510 (RESERVED)
511 RS422 POL 1 Dont Invert
**** ATTACHMENT ****
601 INTERFACE 2 Share
602 IDLE TIMEOUT 05
603 ASCII INTERFACE 0 PARALLEL
* EXTENDED KEYPAD **
704 POR CUSTOM SET 00
Figure 5-2. Configuration Value Printout (ASCII)
