Maintaining the 1330
Connectors
Figure 7-1. Replacing the Print Head
Note: Print head style 2 has a connector at the top of the print head. This connector
does not have to be disconnected when you remove the print head.
Note: Take care that the wiring from the ribbon select motor stays through the carriage
restraining hook. Refer to Figure 7-2.
10. If it is installed, remove the tie-wrap holding the print head wires to the carriage.
Restraining Hook
Figure 7-2. Carriage Restraining Hook
