Reinforced rear mounted attachment
The tractors with power governors may
be equipped optionally with a reinforced
rear mounted attachment with telescopic
lower rods, which are to be installed onto
the shaft with the diameter of 35 mm in-
stead of that with the diameter of 32 mm.
If necessary, the length of the rods equal
to 885 mm may be adjusted stepwise
with the step of ± 80 mm, in this case,
the carrying capacity of the mounted at-
tachment will be varied.
For working with trailed agricultural ma-
chines, the double cross-bar (4) for the
lower telescopic rods (1) with the pivot
(5) is optionally delivered. In this case,
its tips (3) are fitted instead of the rear
ends of the rods (2). The distance from
the end face of the PTO to the pivot
(hitching point) in such version will be
470 mm
ATTENTION! It is strictly forbidden to
use the double cross-bar when per-
forming the transportation works.
