MTZ 952 - Page 93

Operating Instructions
MTZ series 900
93
Rear mounted attachment of the tractors equipped with the hydraulic lift
Machines: mounted (ploughs, cultivators, seeders, cutters, etc.), semi-mounted
(ploughs, soil-tilling units, seeders, potato combines, etc).
Lower rods
Telescopic, one-piece - optional
Length of lower rods, mm:
telescopic
one-piece*
805,885,985
8 8 5
Rod joint width, mm: upper (b1)
lower** (b2)
51
38 or 45
Nominal diameter of attachment components,
mm:
upper rod pin**
lower rod joints (d2)
22 or 25 2 8
Distance from PTO face to hanger axle
595
Load carrying capacity, kN (kgf):
on hanger axle
on 610 mm overhang
43 (4300)
27 (2700)
______________________________________________
* Optional – rods with quickly connectable attachment
* * (Quickly connectable attachment). To be agreed when acquir -
ing the tractor.
