Front Kickboard Removal
Bolted to the front frame directly under the operator’s seat is
an aluminum kickboard. Unbolt the (2) bolts “A” holding in the
kickboard.
Engine Cover Installation
Placing the cover back into the Mudd-Ox is simple. On the
floor is a channel “B” that extends across to both sides of the
vehicle. Place the bottom of the engine cover into this channel.
Then hook the two latches.
Engine Cover Removal
First complete Lower Seats Removal for the rears. Next, locate
the two latches on top of the engine cover and unhook them.
Carefully pull up on the cover and remove it from the vehicle.
Floor Board Removal
(2) metal floor boards are installed in the Mudd-Ox, one per
each occupant area. Fitted is a grab handle to quickly pull the
floors up and out of the machine. Note: You must first com-
plete Lower Seats Removal. When removing the front floor
board, also remove the (2) shift knobs as shown under Front
Kickboard Removal.
AA
BB
Accessing the Mudd-Ox Cont.
