Mudd-Ox XL - Page 99

99
2222
1919
1818
1313
1010
99
1616
1212
1111
88
1515
77
22
33
2020
2121
1414
11
44
66
55
Ref. Qty. Part # Description
1 2 M-1082-L/R Upper Radiator Clamp
2 2 M-3085 Ball Valve
3 2 M-2188 Radiator (RH)
4 2 M-1898 Oil Cooler (RH)
5 2 M-1083-L/R Lower Radiator Clamp
6 2 M-1118 Lower Radiator Clamp Spacer
7 2 M-2180 13" Fan
8 1 M-3086 Fuel Fill Hose
9 1 M-3184 1-1/2" Steel Barb
10 1
M-2005
Brass Fitting
11 1
M-1092
RH Rear Seat
12 1
M-1159
XL Fuel Tank (R-Rollbar)
13 1 M-3260 Sending Unit
14 1
M-1243-3
XL Rear Floorboard
15 2 M-3183 1/2" Steel Barb
16 2 M-3087 Vent Hose
17 1
M-1088
LH Rear Seat
18 2 M-1095 R-Pin
19 2 M-1086 Rollbar Pin
20 4 M-1068 Rollbar Pin Washer
21 1
M-1448
XL Roll Bar
22 2 M-1147 Rollbar Foot Assembly
