Mueller DW-600 - Inlet Hose Connection

Quick
connector
Inlet water
hose
Inlet water
connector
Tap
Connect Inlet
water hose
to the Inlet hose
connector
8
INLET WATER HOSE CONNECTION:
Connecting the Inlet water hose to the Tap:
1. Connect the Quick connector to the Tap.
2. Connect one end of the Inlet water hose to the Quick connector.
3. Connect the other end of the Inlet water hose to the Inlet hose
connector located at the back side of the dishwasher.
3
1
2
