DRAIN HOSE CONNECTION:
LEVEL AND SECURE THE DISHWASHER:
Drain hose
Drain hose connector
Sewer
Drain hose
Dishwasher
Power outlet
Water Inlet hose
Water supply valve
Ensure that the appliance is leveled before operation; otherwise, it may cause an
overflow and electric leakage.
If the dishwasher does not seem level, you can adjust the adjustable feet to
balance the unit. Turn the adjustable foot clockwise to raise the height, and coun-
terclockwise to lower the height.
Bottom vent
21.6x2 in
550x50 mm
A properly loaded dishwasher is key for optimal performance. Never overfill the
dishwasher as it can reduce the unit’s efficiency. Improper placement of items can
also affect the dishwasher’s performance. Position the dishes and utensils so they
are secure during the wash cycle and will not be moved by sprayed water.
NOTE: DO NOT wash items that are not listed as dishwasher safe.
NOTE: Some types of glasses may become dull after a large number of washes.
NOTE: Silver and aluminum may tarnish or discolor during washing.
NOTE: Cast iron items may rust after being washed in a dishwasher.
For best performance, follow these guidelines when loading:
1. Scrape off any large amounts of leftover food. Soak burnt food in pans to
loosen. It is not necessary to rinse the dishes under running water.
2. Place items such as cups, glasses, pots/pans etc. face down so that water will
not collect in them.
3. Curved items, or those with recesses, should be loaded at a slant so that water
can run off.
4. All utensils should be placed in a manner so that they cannot tip over.
5. All utensils should be placed in the way that prevents them from interfering
with the spray arm during washing.
6. Items should not be inside one another or covering other items.
7. DO NOT let large glasses touch each other. Doing so may damage them.
8. Most silverware should be placed in the cutlery basket with handles down.
9. Small knives and sharp objects should be placed handle up to prevent injury.
10. Large sharp objects such as long-bladed knives can present a hazard and
should be placed horizontally in the rack.
11. DO NOT put small items that can fall out of the basket in the dishwasher.
12. DO NOT overload your dishwasher.
13. When pushing the basket back, do not let any sharp utensils cut the door
seal/gasket.
14. The top coating of the basket should not be scratched; otherwise, it may rust.
15. Move the spray arms manually after pushing the basket in, to check if the
spray arms can freely rotate.
1.6in
4 0mm
0.4in
10mm
15.7in
400mm
11in
280mm
Counter
