GPS tracker TV 7”
37
5 Event List (in the
left)
1. Event list shows the all the
events of selected channel.
The event list should be
updated according to the
selected channel.
2. After display the EPG
Menu, the focus is in the cur-
rent event (of corresponding
channel), and the current
event is displayed in the first
item of the event list.
For example:
3. Tap the scroll bar can
navigate the event list
6 Event Item:
Current Event Item:
1. This is the event list item
2. Current event (of corres-
ponding channel) will be
highlight as:
3. Tap the Info icon of event
will display the event
description.
7
Tap “ ” or “ ”, icon, can
display the events of pre day
or next day. For example:
8
This is the favorite icon.
1. Tap will add corres-
ponding channel into favorite
channel list, and the icon will
change to
2. Tap will remove
corresponding channel into
favorite channel list, and the
icon will change to
3. All channels marked as
favorite will be shown in
favorite channel list.
9
Tap info button will show the
description of selected event.
Please refer to event info
8.5.1 Event Info
Tap
icon of event item will display the description of the
event in the left, and display all events of current channel in
the right.
Index GUI Component Usage Description
1 Event List (on the
right)
1. Will show shows the
all the events of selected
channel here
2. After display this Menu,
the focus is in the current
event
3. Tap the scroll bar can
navigate the event list
2 Event Item:
Current Event Item:
1. This is the event list
item
2. Current event will be
highlight as:
3 Display event description
here
4
Tap “Back” button will
back to EPG menu.
8.6 Settings
Setting Menu includes 3 sub-menus, Channel Scan, General
Settings and About Sub-Menu.
8.6.1 Channel Scan
