MULTIQUIP WHITEMAN MD105 - Spray Wiring Diagram; Retardant Spray System Wiring

PAGE 56 — MD105 RIDE-ON TROWEL • OPERATION MANUAL — REV. #0 (03/29/24)
SPRAY WIRING DIAGRAM
LEFT-SIDE
SPRAY PUMP
RIGHT-HAND
SPRAY SWITCH
LEFT-HAND
SPRAY SWITCH
RIGHT-SIDE
SPRAY PUMP
FUSE AND
RELAY BOX
FRAME
HARNESS
J2
934447111
MAIN
HARNESS
P17
934457111
Z40
Z39
Z16
Z6
Z43
Z9
MAIN
HARNESS
P12
DT06-2S
MAIN
HARNESS
P4
DT06-2S
FRAME
HARNESS
J3
DT04-2P
FRAME
HARNESS
J4
DT04-2P
Z7
18 AWG
BL
18 AWG
BL
18 AWG
BK/OR
16 AWG
BK/OR
18 AWG
RD/BK
18 AWG
RD/BK
18 AWG
RD/BK
18 AWG
RD/GN
16 AWG
BK/YL
18 AWG
BK/YL
18 AWG
RD/BK
18 AWG
RD/BL
18 AWG
RD/BK
16 AWG
RD/BK
16 AWG
RD/BK
16 AWG
RD/BK
16 AWG
RD/BK
12
17
1
7
13
17
11
11
1 2
1
2
1
2
C G P M
I
BUS BAR
MAIN
HARNESS
P7
DT06-12SA
J1
13
11
16 AWG
BK/YL
H
