MULTISPAN AVH-14N - Technical Specification; Maximum Demand

PowerSupply
Maximum
Current
Operating
Relative

&

Key


Voltage

Sensing
100To250VAC,50/60Hz,Approx4VA
CTratioisselectable(UPto6000/5A)
3Phase4Wire/3Phase3WireSystem
0°CTo55°C
Upto95%RHNonCondensing
ManualorAutoMode
50To500VAC(P-P)CATIII
30To300VAC(P-N)CATIII
Model
Size(mm)
Display
PanelCutout
InputCurrent
96(H)X96(W)X50(D)mm
UPPER:7Seg,6digit,0.40,REDLEDdisplayforKWH
LOWER:7Seg,4digit,0.40,REDLED
92X92mm
AVH-14N
50mAto5AMPAC,(WITHOUTCT)CATIII
Protection


(Asperrequest)
IP-65(Frontside)AsperIS/IEC60529:2001
www.multispanindia.com
Page-1
AVH-14N
ConnectionDiagram
TechnicalSpecification
Maximum Demand
1
2
3
4
7 8
9
12
1314
10
11
5
1617181920
6
15
S1 S1 S1 S2S2S2
R
Y
B
VR
VY
VB
N
System : 3 Ph-4W,
3 Ph-3W
Accuracy Class: 1.0
Range
Current: 50mA To 5A AC, CAT III
Voltage(P-P) : 50-500V AC, CAT III
(P-N) : 30-300V AC, CAT III
L
N
~
50/60 Hz
4VA
100
250V AC
!
*Themaximumdemandvalueisthemaximumaveragevalueofthe
instantaneouspowerduringadefinedtimeintervalsetinMDTime
parameter.ThedefaultvalueofMDtimeis15minutes,whichis
selectable.
Note
*PresskeyforSCROLL&HOLDFacility.
*BydefaultvalueofMDTimeis15minutes.
AVH 14N
KWH
Hz
KW-Ø
PF-Ø
   
     
   
   
.
.
.
Level
Temperature
Humidity
