MULTISPAN MDT-4310N - Parameter Setting Guide; Time Unit Configuration; Time Range Selection; Operating Relay Mode

www.multispanindia.com
Page-3
MDT-4310N
Reset Key + Power ON
OUT
Press reset key to Save & Exit
(Press reset key to change parameter value)
(Press reset key to change parameter value)
(Press reset key to change parameter value)
(Press reset key to change parameter value)
(Press reset key to change parameter value)
(Press reset key to change parameter value)
Thumbwheel
Switch Position
Time unit (Sec,Min,Hour)
Time Range:
Auto Manual Mode
( IF Time = 0 then manual mode is selected
IF Time = 0 (Range 1 - 99 SEC.) then auto mode selected)
(999,99.9,9.99 For Sec.)
(999,99.9 For Min.)
(999,99.9 For Hour.)
Memory ( YES Or NO)
Operating Relay Mode (Delayed ON, Delayed OFF)
Counting Direction (UP Or DOWN)
1 0 0
2 0 0
3 0 0
4 0 0
5
0 0
6
0 0
7
0 0
8
0 0
9
0 0
0
0 0
