MultiTable Manual ModTable - Mounting the Center Crossbars

15 pages

To Next Page

To Previous Page

Page 10 | ModTable | vs 5.0

6

#18

# Description Qty

18 Set screws 4

21 Medium Allen wrench 1

3.4.4 Mounting the Center Crossbars Continued

Important! Photo 6:

 Fully tighten the set screws in the drive shaft using the Medium Allen wrench. Tighten

set screws three times on each side to ensure screws are completely tightened. Set screws

MUST be tightened completely for the Base to function properly.
