Chapter 14 – SIM Toolkit
Multi-Tech Systems, Inc. Wireless GSM/GPRS AT Commands (Document Number S000293I) 147
Values when CmdType=0 (Select an item from the main menu)
<Result>
1 Item selected by the user.
2 Help information required by user.
<Data> Contains the item identifier of the item selected by the user.
Values when CmdType=1 (Confirm the display text clearing)
No values.
Values when CmdType=2 (Get Inkey)
<Result>
0 Session ended by user.
1 Response given by the user.
2 Help information required by user.
<Data> Contains the key pressed by the user.
Values when CmdType=3 (Get Input)
<Result>
0 Session ended by user.
1 Response given by the user.
2 Help information required by user.
<Data> Contains the string of characters entered by the user.
Note: For Inputs in UCS2 format, the data are entered in ASCII format. Example: For
“8000410042FFFF” entered, the SIM receives 0x00 0x41 0x00 0x42 with UCS2 DCS. (See the
Appendix G about the different UCS2 syntaxes).
Values when CmdType=4 (Setup call)
<Result>
0 User refuses the call.
1 User accepts call.
Values when CmdType=6 (Select Item)
<Result>
0 Session terminated by the user
1 Item selected by the user
2 Help information required by the user
3 Return to the back item
<Data> Contains the item identifier selected by the user
Values when CmdType=11 (Setup Event List)
<Result>
1 Idle screen available.
2 User activity event.
Sending a Terminal Response to the SIM:
Values when CmdType=95 (Backward Move)
Values when CmdType=96 (Command beyond ME capabilities)
Values when CmdType=97 (ME currently unable to process command)
Values when CmdType=98 (No response from the user)
Values when CmdType=99 (SIM Toolkit Session aborting by the user)
No values.
It is possible to send a Terminal Response after the +STIN indication (step 2, of Messages exchanged during a SIM
Toolkit operation), or after the +STGI command (step 3).
Note: For the SETUP MENU Proactive Command, it is only possible to send a Terminal Response after the +STIN:
0 indication, not after a +STGI=0 request. All of the Terminal Responses are not possible with all of the
Proactive Commands. Compatibility between available Terminal Responses and Proactive Commands is
given in Appendix D, Table 2. If a Terminal Response is attempted during a incompatible Proactive Command
session, a +CME ERROR: 3 will be returned.
Possible error codes
+CME ERROR: 3 Operation not allowed. This error is returned when a wrong parameter is detected.
+CME ERROR: 4 Operation not supported. This error is returned when the user gives a response with
SIM Toolkit functionality not activated. Or if the SIM Toolkit indication (+STIN) has not
been received.
