Chapter 3 - AT Commands, S-Registers and Result Codes
55
Register Unit Range Default Description
S23
General Bit Mapped Options Status (Indicates the status of com-
mand Options.) Default: 62 (3Dh)
Bit 0 Grant RDL
0 = RDL not allowed (&T5)--Default
1 = RDL allowed (&T4)
Bit 1-3 DTE Rate
0 = 0-300 bps
1 = 0600 bps
2 = 1200 bps
3 = 2400 bps
4 = 4800 bps
5 = 9600 bps
6 = 19200 bps
7 = 38400 bps or higher (Default)
Bit 4-5 Assumed DTE parity
0 = even
1 = not used
2 = odd
3 = none (Default)
Bit 6-7 Guard Tone (&Gn)
0 = none (&G0)--Default
1 = none (&G1)
2 = 1800 Hz (&G2)
S24
seconds 0–255 0 Sets the length of time, in seconds,
that the modem operates in normal
mode with no detected telephone or
DTE line activity before entering low-
power sleep mode. The timer is
reset upon any DTE or Telephone
line activity.
S25
seconds 0–255 5 Sets the length of time, in seconds,
that the modem ignores DTR for
taking the action specified by &Dn.
Its units are one hundredths of a
second.
