Page3of17
IMC08 Maintenance Manual
Version 1.01
Contents
Version History................................................................................................................... 2
1.0. Overview................................................................................................................. 4
2.0. Cleaning the Machine .............................................................................................. 5
2.1. Clean the Hopper ................................................................................................................5
2.2. Clean the Stacker and Reject Pocket ..................................................................................5
2.3. Clean the Internal Sensors..................................................................................................5
3.0. Error Analysis ......................................................................................................... 7
3.1. Error Code ..........................................................................................................................7
3.2. Bill Jam ...............................................................................................................................7
3.2.1. Bill stuck in the feeding port (PS1 Error) .....................................................................8
3.2.2. Bill stuck in the inside of machine (PS3R Error)..........................................................9
3.2.3. Bill stuck in the reject pocket (TD Error) .....................................................................9
3.3. Sensor Errors.................................................................................................................... 10
3.3.1. Hopper Sensor Error ................................................................................................ 10
3.3.2. Stacker Sensor Error ................................................................................................ 10
3.3.3. Counting Sensor Error .............................................................................................. 10
3.4. Feeding Gap Calibration ................................................................................................... 11
3.5. CIS Calibration.................................................................................................................. 13
3.6. Back to Default Setting ..................................................................................................... 15
