3.0. Error Analysis
3.1. Error Code
Table 3-1 Error Codes
Handling Method (Recommendation)
Remove the banknote, clean the UV sensor
If the errors occur frequently, adjust the screw toward the anti-clockwise to
decrease the feeding gap.
Clean the CIS sensor, and calibrate the CIS
Remove the banknote, clean the CIS sensor;
Perform the CIS sensor calibration;
Collect the data of the banknote.
Orientation Recognition Error
Remove the banknote, clean or replace the MG sensors
Remove the banknote, clean the CIS sensor;
Perform the CIS calibration;
Collect data of the banknote.
In the process of using the IMC08, the IMC08 may show abnormal state and display the error codes on the screen.
The description of the error codes and the related handling method is shown in table 3-1.
3.2. Bill Jam
There are several conditions to make the bill jam happened.
1) The bill size is out of the range according to IMC08 specification.
2) The banknote is damaged with different ways such as lack of corner, tape, hole, tear and folded. As shown in
Figure 3-2, it is not recommended to count this kind of bills.
