9.4. Technical data
Process air
(1)
Free-blowing air 50/60 Hz (m³/h) 225
Rated airflow at 60 Pa (m³/h) 190
Max. static pressure 50/60 Hz (Pa) 300
Fan motor power (kW) 0,09
Reactivation air
(1)
Rated airflow at 90 Pa (m³/h) 30
Max. static pressure (Pa) 260
Fan motor power (kW) -
(2)
Reactivation air heater
Heater power (kW) 0,84
Factory set reactivation temperature (Rt) limit (°C) 130
Factory set wet air temperature (Wt) limit (°C) 75
Temperature increase across heater (°C) 100
Other
Sound pressure level, free blowing process fan (dBA) 58
IEC protection class (unit) IP33
IEC protection class (electrical panel) IP54
Fan motor winding insulation class Class B
Drive motor winding insulation class Class B
Rotor type HPS
Environmental conditions
Operating temperature (°C) -20... +40
Maximum installation altitude, above sea level (m) 2000
Transport and storage temperature (°C) -20... +70
Total power, voltage and current
Voltage (V) 115 230
Frequency (Hz) 50/60 50/60
Total power (W) 950 950
Current (A) 8,2 4,1
Fuse 3 AG, 250 VAC, 10
A Slow
3 AG, 250 VAC, 6 A
Slow
(1)
The specified performance is based on 20 °C and air density of 1.2 kg/m³.
(2)
The same fan is used for process air and reactivation air.
