Appendix: Unit Specific Information 24
DryCool HD Operator and Maintenance Manual P00960167-1
Munters DryCool HD drier testing and analysis for measurement taken on process side of system. Available
external Sp measured at 60Hz, 81 deg F Tro.
Munters Drycool HD Process Side
Process
Airflow
Available Ext Sp
"wg
ACFM at fan 60 Hz measured
185.0 0.62
185.0 0.62
213.3 0.53
213.3 0.53
233.6 0.44
233.6 0.44
250.2 0.37
250.4 0.37
275.7 0.26
275.6 0.26
290.4 0.18
290.6 0.18
