DehumidierML420-MLT1400
2.3Maincomponents
11
1
4
5
6
8
9
2
16
3
12
14
13
15
10
7
Figure2.2Maincomponents
1.Lowerrotorcover9.Drivemotor
2.Roller,beltguide10.Pulley,beltdrive
3.Drivebelt11.
Reactivationairlter
4.Rotor12.Reactivationairimpeller
5.
Sealingring,rotor
13.
Reactivationfanmotor
6.Upperrotorcover14.
Processfanmotor
7.
Electricalcontrolpanel15.Processairimpeller
8.Reactivationheater16.
Processairlter
NOTE!TheML420unithasonlyonefanmotorthatisplacedbetweentheprocessandreactivationimpeller.
190TGB-1035-H1604Dehumidierdesign5
