MX²40E CorrectionKok dB atISO-band centrefrequency,Hz
Setup Lp(A)100m
2
Lwt
(dB)
63 125 250 500 1000 2000 4000 8000
A 71 90 -9 -5 -8 -7 -11 -14 -17 -18
B 73 93 -8 -4 -10 -6 -14 -17 -20 -22
C
71 91 -8 -4
-7
-10 -12 -14 -16 -20
D7292-6
-5
-9 -8 -13 -16 -17 -19
MX²55E CorrectionKok dB atISO-band centrefrequency,Hz
Setup Lp(A)100m
2
Lwt
(dB)
63 125 250 500 1000 2000 4000 8000
A7190
-7
-4 -10 -9 -9 -14 -15 -19
B7293
-7
-3 -9 -9 -11 -15 -19 -22
C
70 91 -10 -3 -8 -10 -12 -14 -16 -20
D 72 93 -6 -3 -11 -10 -12 -17 -18 -22
MX²60E CorrectionKok dB atISO-band centrefrequency,Hz
Setup Lp(A)100m
2
Lwt
(dB)
63 125 250 500 1000 2000 4000 8000
A7392-6
-7
-6 -10 -10 -16 -14 -14
B 75 94 -7 -8 -7 -5 -12 -18 -16 -15
C7393-6-6
-7
-11 -11 -17 -14 -15
D
75
94
-7
-8
-7
-6 -12 -16 -16 -15
MX²80E CorrectionKok dB atISO-band centrefrequency,Hz
Setup Lp(A)100m
2
Lwt
(dB)
63 125 250 500 1000 2000 4000 8000
A 76 95 -5 -7 -7 -10 -10 -15 -14 -16
B7897-6-8-8
-5
-11 -17 -16 -16
C
76 96
-5
-6 -8 -11 -10 -15 -15 -16
D 78 97 -6 -8 -8 -6 -12 -15 -16 -16
MX²95E CorrectionKok dB atISO-band centrefrequency,Hz
Setup Lp(A)100m
2
Lwt
(dB)
63 125 250 500 1000 2000 4000 8000
A7697
-5 -5
-9 -12 -12 -13 -15 -19
B7998
-5 -7
-9 -8 -12 -13 -18 -20
C
76 97 -5 -4 -9 -10 -13 -14 -18 -19
D 79 98 -5 -6 -8 -8 -12 -13 -17 -21
Table8.2Noisetoroom
