3-33
Memory Switch G:5 - Remote reception
Switch
Initial
Setting
Adjust Usage/Comments
7 0
6 0
5 0
4 0
Adjust the detect time for
regarding as the CI signal.
Increase/decrease the time specified in this switch
from the standard detect time. Determine it in G:5
bit 3 whether increase or decrease.
Switch 7 6 5 4 Time
0 0 0 1 10 msec
0 0 1 0 20 msec
0 0 1 1 30 msec
1 1 1 1 150 msec
3 0 Adjust the detect time for
regarding as the CI signal.
0: decrease
1: increase
Increase/decrease the time specified in G:5 bit 4 to
7 from the standard detect time.
2 0 Factory use only
1 0 Factory use only
0 0 Beep if fax handset hang up
0: Yes
1: No
Determines if your fax beeps when having left the
fax’s handset hanging up after communication.
Memory Switch G:6 - Remote reception and TAD interface
Switch
Initial
Setting
Adjust Usage/Comments
7 0
6 0
5 0
4 0
3 0
2 0
1 0
0 0
Off-hook / on-hook detect
time for remote reception
Sets the time interval between the off-hook/on-hook
condition for remote reception. The total time of this
time and the time specified in G:1 bit 4 to 7 will be
the actual time.
Switch 7 6 5 4 3 2 1 0 Time
0 0 0 0 0 0 0 0 0 ms
Initial setting
0 0 0 0 0 0 0 1 20 ms
0 0 0 0 0 0 1 0 40 ms
0 0 0 0 0 0 1 1 60 ms
0 0 0 0 0 1 0 0 80 ms
1 1 1 1 1 1 1 0 5080 ms
1 1 1 1 1 1 1 1 5100 ms
Memory Switch G:7 ∼
∼∼
∼ G:9 --- Factory use only
