3-34
Memory Switch H:0 - Operation
Switch
Initial
Setting
Adjust Usage/Comments
7 0 Display error line
0: No
1: Yes
The number of error lines contained in the received
data will be shown in the LCD.
6 0 Total line monitor
0: No
1: Yes
Allows fax communication to be heard through the
monitor speaker.
5 0 Factory use only
4 0 Sort autodialer printout
0: Sort by autodialer location
1: Sort by location ID
Specifies how entries on autodialer printouts are
sorted.
3 1 Print check message if power
is lost
0: No
1: Yes
In the event of two power losses in a 40 hour
period, documents will be lost. When power is
restored, a check message will print.
2 1 Print page if error occurs
during memory transmission
0: No
1: Yes
For easy identification, the first page of a document
stored for memory transmission will print along a
check message if an error occurs during memory
transmission.
1 1 Print check message
0: No
1: Yes
To notify the user of an error, a check message can
be printed if a communication error occurs.
0 0 Stop printing check message
for a memory transmission by
pressing the stop key
0: No
1: Yes
Determines if pressing the stop key stop printing the
check message for a memory transmission.
Memory Switch H:1 - Operation
Switch
Initial
Setting
Adjust Usage/Comments
7 0 Factory use only
6 0 Factory use only
5 1 Print TCR with the original
page
See table below
4 0 Factory use only
3 1 Print TCR with the original
page
0: No
1: Yes
For easy identification, the first page of a document
stored for memory transmission will print along a
TCR.
2 0 Factory use only
1 0 Factory use only
0 0 Display modem speed
0: No
1: Yes
The transmit/receive speed is displayed in the LCD.
Memory switch H:1 … Print TCR with the original page
Switch 3 0 1
Switch 5 0 1 0 1
When Memory transmission was OK, … No No Yes Yes
When Memory transmission was NG, … No Yes No Yes
When all broadcast transmissions were OK, … No No Yes Yes
When some broadcast transmissions were NG, … No Yes No Yes
