Active panel
Settings are made from the control panel.
Remote control unit
Settings are made from the remote control unit.
The remote control unit must be connected to the remote control unit socket on the
machine before activation. When the remote control unit is activated the panel is
inactive.
VRD (Voltage Reduction Device)
Note! The VRD function is not active (LED has gone out) on delivery. Contact an
authorised ESAB service technician to activate the function.
The VRD function ensures that the open--circuit voltage does not exceed 35 V when
welding is not being carried out. This is indicated by a lit VRD LED. The VRD
function is deactivated when the system senses that welding has started.
If the VRD function is activated and open--circuit voltage exceeds the 35 V limit, this
is indicated by an error message (16) appearing in the display and welding cannot
be started whilst the error m essage is displayed.
10 MAINTENANCE
Regular maintenance is important for safe, reliable operation.
Only those persons who have appropriate electrical knowledge (authorized
personnel) may remove the safety plates.
CAUTION!
All guarantee undertakings from the supplier cease to apply if the customer himself
attempts any work in the product during the guarantee period in order to rectify any faults.
10.1 Power source
Check regularly that the welding power source is not clogged with dirt.
How often and which cleaning methods apply depend on:
S the welding process
S arc times
S placement
S the surrounding environment.
