T ransarc 250
Power factor at maximum current
MMA
TIG
0.94
0.93
Efficiency at maximum current
MMA
TIG
83 %
79 %
Open --circuit voltage
without VRD
with VRD
65 V
<35V
Operating temperature -- 1 0 t o + 4 0 ˚C
T ransportation temperature -- 2 0 t o + 5 5 ˚C
Continual sound pressure at no--load <70db(A)
Dimensions lxwxh 418 x 188 x 208 mm
Weight 10.5 kg
Insulation class transformer H
Enclosure class IP 23
Application class
Mains supply, S
sc min
Minimum short circuit power on the network in accordance with IEC 61000--3--12
Duty cycle
The duty cycle refers to the time as a percentage of a ten--minute period that you can weld at a cer-
tain load without overloading. The duty cycle is valid for 40˚C.
Enclosure class
The IP code indicates the enclosure class, i. e. the degree of protection against penetration by solid
objects or water. Equipment marked IP23 is designed for indoor and outdoor use.
Application class
The symbol indicates that the power source is designed for use in areas with increased
electrical hazard.
5 INSTALLATION
The installatio n must be executed by a p rofessional.
5.1 Location
Place the power source so that its cooling air inlets and outlets are not obstructed.
5.2 Mains supply
Note!
Mains supply requirements
High power equipment may, due to the primary current drawn from the mains supply, influence the
power quality of the grid. Therefore connection restrictions or requirements regarding the
maximum permissible mains impedance or the required minimum supply capacity at the interface
point to the public grid may apply for some types of equipment (see technical data). In this case it
is the responsibility of the installer or user of the equipment to ensure, by consultation with the
distrubution network operator if necessary, that the equipment may be connected.
