Murex Transarc 250 - Page 20

Transarc 250
R0460 810 074/E080825/PNO T AG
-- 2 0 --
bh36saa1
C = component designation in the circuit diagram
Item Qty Ordering no. Denomination Notes C
AA1 1 0460 479 003 Side cover Left
AA2 1 0458 950 001 Sign
AA3 4 0366 588 001 Nut 4--K
AA4 1 Front panel Included in item AA50
AA6 1 0460 690 005 Label Transarc 250
AA7 2 0160 362 026 OKC 50 contact Welding connection, Included in item AA50 XS1, XS2
AA8 2 0366 306 003 Spring washer Ø 21/15 x 1, included in item AA50
AA9 2 0366 247 001 Nut 6--k brass, included in item AA50
AA10 1 0366 285 001 Protection cap For 12--pole connection, included in item AA50
AA11 1 0460 482 887 Cable with connection Included in item AA50 29XS7
AA12 1 0460 600 528 Knob Included in item AA13
AA13 1 0460 476 884 MMC Module Complete, configured
1 0460 420 001 Insulation sticker Inluded in item AA13
AA14 1 0193 700 711 Ribbon cable with connectors 1XS1, 1XS2
AA15 1 0460 479 004 Side cover Right
AA16 1 0460 140 002 Rear panel
AA17 6 0469 381 002 Fast look nut M5
AA18 1 0460 424 880 Main switch Complete 2QF1
AA19 1 0349 891 207 Motor plug 2XT1
AA20 1 0456 193 882 Mains cable 4G1.5 grounded
AA21 1 0194 034 001 Ferrite core 2L1
AA22 1 0460 143 001 Cover
AA23 1 0460 265 001 Strap
AA24 2 0468 497 001 Holder
SPARE PARTS SETS
Item Qty Ordering no. Denomination Notes
AA50 1 0460 379 895 Front complete Includes items AA4, AA7, AA8, AA9, AA10 and AA1 1.
When replacing “front complete” also item AA13, MMC module,
must be replaced.
