Transarc 250
R0460 810 074/E080825/PNO T AG
-- 2 2 --
bh34sab1
C = component designation in the circuit diagram
Item Qty Ordering no. Denomination Notes C
AB1 1 0192 790 102 Circuit card holder
AB2 1 0487 584 880 Printed circuit board EMC board 2AP1
AB3 1 0194 034 002 Ferrite core 2L3
AB4 1 0459 197 887 Control module (VRD) digital Control board 20AP1
AB5 1 0457 304 880 Shunt 15RS1
AB6 2 0468 538 002 Current bar
AB7 1 0460 423 001 Bar minus
AB8 1 0460 375 880 Coil inductor complete 15L2
AB9 2 0460 373 001 Ferrit core
AB10 1 0487 588 880 Printed circuit board Power supply 2AP2
AB11 1 0193 700 719 Ribbon cable with connectors 20XS3,
20XS4
AB12 1 0460 312 001 Heat sink rectifier
AB13 1 0487 618 880 Printed circuit board LC filter 15AP2
AB14 1 0460 117 001 Inductor PFC 17L1
AB15 1 Printed circuit board PFC board, included in item AB50 17AP1
AB16 1 0193 700 717 Ribbon cable with connectors 17XS3,
17XS4
AB17 1 Primary module Included in item AB50
AB18 1 0460 501 001 Rail DC--buss
AB19 1 0394 516 034 Spacing screw M5x15
AB20 2 0394 516 038 Spacing screw M5x30
AB21 4 0192 790 102 Spacer 6.3 mm
AB22 2 0192 790 104 Spacer 12.7 mm
AB23 1 0192 790 109 Spacer 28.6 mm
SPARE PARTS SETS
Item Qty Ordering no. Denomination Notes
AB50 1 0460 653 881 PFC--board kit Includes item AB14, AB15, AB17 screws (type A and B), 2 ca-
pacitors 470 ìF, 2 capacitors 1 ìF, thermal compound and roller
0458 910 002 Roller handle For the roller in the spare parts sets above
0192 058 101 Thermal compound
