Transarc 250
R0460 810 074/E080825/PNO T AG
-- 2 4 --
bh34sac1
C = component designation in the circuit diagram
Item Qty Ordering no. Denomination Notes C
AC1 1 0460 329 880 Transformer 15TM1
AC2 1 0460 414 001 Fan 15EV1
AC3 1 0460 312 001 Heat sink rectifier Inverter
AC4 1 Primary module Included in AC50
AC5 1 Printed circuit board Power board, Included in AC50 15AP1
AC6 1 0460 484 001 Cu--bar
AC7 1 0190 209 118 Hose L =0.04 m, Ø 12 mm, To be ordered per metre
AC8 3 0193 948 001 Diode module 15D1, 15D2,
15D3
AC9 1 0460 413 001 Rail, secondary
AC10 1 0460 338 001 Heat sink for secondary diod
AC11 1 0394 516 023 Distancescrew M4x25
SPARE PARTS SETS
Item Qty Ordering no. Denomination Notes
AC50 1 0460 653 880 Power board kit Includes item AC4, AC5, screws (type A and B), thermal com-
pound and roller
0458 910 002 Roller handle For the roller in the spare parts sets above
0192 058 101 Thermal compound
To Next Page
