Murr Elektronik IMPACT67-P User Manual

V 1.6 17
Bit assignment for DO8 (Art.No.: 55347) / DI16 (Art.No.: 55345) /
DO16 (Art.No.: 55348)
Bit assignment 1st byte: relevant for DO8, DI16, DO16
7 6 5 4 3 2 1 0
M12 socket 0 channel 00 (Pin 4)
M12 socket 1 channel 01 (Pin 4)
M12 socket 2 channel 02 (Pin 4)
M12 socket 3 channel 03 (Pin 4)
M12 socket 4 channel 04 (Pin 4)
M12 socket 5 channel 05 (Pin 4)
M12 socket 6 channel 06 (Pin 4)
M12 socket 7 channel 07 (Pin 4)
Fig. 8: Bit assignment 1st byte
Bit assignment 2nd byte: relevant for DO16, DI16
7 6 5 4 3 2 1 0
M12 socket 0 channel 10 (Pin 2)
M12 socket 1 channel 11 (Pin 2)
M12 socket 2 channel 12 (Pin 2)
M12 socket 3 channel 13 (Pin 2)
M12 socket 4 channel 14 (Pin 2)
M12 socket 5 channel 15 (Pin 2)
M12 socket 6 channel 16 (Pin 2)
M12 socket 7 channel 17 (Pin 2)
Fig. 9: Bit assignment 2nd byte
