IMPACT67-P manual
16 V 1.6
3.3 Configuration
It is necessary to configure a Profibus DP Slave to define the I/O data quantity and to reserve
addresses in the controller.
IMPACT67-P represents a physically compact device. However, it is treated as a modular
system in the DP system.
Data Module Format
Header Modules Data Width ID
IMPACT67-P DI16, 55 345 2 bytes 00
he
x
11
hex
IMPACT67-P DI8/DO8, 55 346 2 bytes 20
he
x
10
hex
IMPACT67-P DO8, 55 347 1 byte 20
he
x
00
hex
IMPACT67-P DO16, 55 348 2 bytes 21
he
x
00
hex
Table 3: Data Module Format
Relationship between Channel Number and Pin/Socket
The channel number defines the socket and the associated pin. Example: Channel number is
12, this corresponds to Pin 2 (x=1) of socket no. 2 (Y=2).
Channel Number = XY X
Y
X = 0 Pin 4
X = 1 Pin 2
Y = 0 to (number of sockets) Number of socket
Table 4: Relationship between Channel Number and Pin/Socket
