Battery Cables Parameters
Specication AWG Cross-sectional area/mm² Outer diameter/mm
1200W/12V 5AWG 16 4.51
1500W/12V 4AWG 20 (10*2) 5.05
2000W/12V 3AWG 25 5.64
2000W/24V 5AWG 16 4.51
2500W/12V 2AWG 35 6.67
2500W/24V 4AWG 20 (10*2) 5.05
3000W/12V 2AWG 35 6.67
3000W/24V 4AWG 20 (10*2) 5.05
3500W/12V 1/0AWG 50(25*2) 9.42
3500W/24V 3AWG 25 6.67
4000W/12V 2/0AWG 70 (35*2) 9.42
4000W/24V 2AWG 35 6.67
4000W/48V 5AWG 16 4.51
5000W/24V 2AWG 35 6.67
5000W/48V 4AWG 20 (10*2) 5.05
NOTE:
In practice, a thick battery cable can be replaced by two thin battery
cable as long as the total section area of the battery cables meets the
requirements.
The cable needs to be thick enough to carry the current. Otherwise, the
battery cable with small cross-sections could cause a voltage drop that
prevents the inverter from supplying large loads.
When the input current of the power supply is large, the input battery
cable may have a voltage drop. The actual working voltage depends on the
measured value of the input terminal of the inverter. If the voltage drop
is too much, it may be necessary to increase the cross sectional area or
reduce the length of the battery cable.
