MWXNE MW2000 - Components Overview; Panel Introduction

16
① I n d i c a t o r L i g h t
(red-fault, green-normal)
② P o w e r S w i t c h
③ Remote Control Jack
④ Earth Wire
⑤ QC 3.0 18W USB Port
① I n d i c a t o r L i g h t
(red-fault, green-normal)
② P o w e r S w i t c h
③ Remote Control Jack
④ Earth Wire
⑤ QC 3.0 18W USB Port
⑥ QC 3.0 24W USB Port
⑦ PD 60W Type-C Port
⑧ AC Socket
⑨ Cooling Fan
⑩ Positive Terminal
⑪ Negative Terminal
⑥ QC 3.0 24W USB Port
⑦ PD 60W Type-C Port
⑧ AC Socket
⑨ Cooling Fan
⑩ Positive Terminal
⑪ Negative Terminal
Components Overview
MWP600W/1200W
MWP2000W/2500W
Panel Introduction
