7. Loader hitching
This operation must be carried out by the driver, who must exit the cab and ensure all
manoeuvres are prohibited while working on the loader.
Watch the unhitching/hitching video at www.m-x.eu
— Advance the tractor slowly so that the bracket is approx. 5 cm
behind the frames.
— Apply the hand brake. Stop the engine.
■
— Connect the hydraulics and the electrics. Loader with MACH
System:
- Ensure that the male and female couplings are clean before
hitching. Clean them if necessary.
- Take the housing in both hands and, with its back facing away,
lift the control valve cover onto the guide bars and engage
vertically.
■
— Connect the hydraulics and the electrics. Loader without MACH
System:
- Remove the caps
- Connect the hydraulic couplers
- Open the valve.
■
