14
Subject to modication
5. Control
Reminder: Never leave the tractor with the loader lifted.
Every control valve with spool generates an internal leak required for proper operation.
5.1 Control using the tractor's control valves
Refer to the user manual for the tractor.
■
5.1.1 Front/rear control selector (optional)
From the tractor's original joystick, the user in the cab controls
either the MX loader or the rear couplings.
■
5.2 Control with the MX control valve
■
5.2.1 Handle setting *
To ensure comfortable control of the loader, the handle's position
can be adjusted.
* on Propilot and Flexpilot controls only.
■
5.3 Control with MX PROPILOT control valve
■
