MX F300 Series - Page 38

F303 F304
Mechanical parallelogram NO YES
Length (A) 2.05 m 2.05 m
Width (B) 1.15 m 1.20 m
Height (C) 1.55 m 1.65 m
Min. weight (with no option) 375 kg 422 kg
Max. height at implement pivot* 3.20 m 3.20 m
Max. height under horizontal bucket (1) # 2.95 m 2.95 m
Max. height under dumped bucket (2) # 2.40 m 2.40 m
Digging depth (3) # 0.15 m 0.15 m
Dumping angle at full height (4) # 48° 48°
Crowd angle at ground level (5) # 45° 45°
Lifting force at implement pivot* 1550 kg 1550 kg
Lift capacity at implement pivot over the entire lifting 1400 kg 1400 kg
Payload on pallet at 0.60 m out on forks
On the ground 950 kg 1200 Kg
At 2 m above ground 875 kg 1175 kg
At 3 m above ground 770 kg 1175 kg
At max. height 750 kg 1175 kg
Lifting time 3 sec 3 sec
Dumping time 1.4 sec 1.4 sec
NOTE: Specications determined at 190 bar pressure and with a ow rate of 60 litres/min.
Data may vary depending on the type of tractor being equipped. * Figures provided for a general purpose bucket.
Only payloads are counted. The gures at ground level and at the implement pivot axis are not to be used.
■
