MXN MXN-P7DQ - Installation

7" TFT DIGITAL LCD Monitor
14
▣ INSTALLATION
MONITOR installation with STAND BRACKET & SUNVISOR
Remove a protection tape and attach STAND BRACKET into stand place, then x it with the
supplied screws.
Connect STAND BRACKET with monitor and adjust height/angle.
Connect SUNVISOR to the MONITOR.
Connect CAMERA INPUT CABLE to the MONITOR.
A
B
C
D
A
ⓐ
ⓑ
B
C
D
