MXN-P7DQ
Owner’s Manual
7
CAMERA TRIGGER
DISTANCE MARKER
CAMERA TRIGGER
TRIGGER 1 CAM1-QUAD
TRIGGER 2 CAM1-QUAD
TRIGGER 3 CAM1-QUAD
TRIGGER 4
CAM1-QUAD
TRIG 1. DELAY
2 (0-9)
TRIG 2. DELAY
2 (0-9)
TRIG 3. DELAY
2 (0-9)
TRIG 4. DELAY
2 (0-9)
DISTANCE MARKER
TRIGGER 1 ON
TRIGGER 2 OFF
TRIGGER 3 OFF
TRIGGER 4 OFF
MARKER /
TRIGGER 1/2/3/4 (Trigger source selection)
Select the required trigger source at CAM1/CAM2/CAM3/CAM4/AUX/SPLIT/TRIPLE/QUAD
REMARK
TRIGGER PRIORITY: TRIGGER 1 > TRIGGER 2 > TRIGGER 3 > TRIGGER 4
TRIG. DELAY
When a TRIGGER wire is connected to a pulse DC power signal (e.g.direction indicator
lights) then the [TRIGGER DELAY] function avoids repeating ON/OFF of the monitor.
Select ON to have DISTANCE MARKER for CAM1, CAM2, CAM3, CAM4.
DISTANCE MARKER is displayed as the trigger signal is activated.
Select of DISTANCE MARKER. or
MARKER
