2205B0JE-DA-J-N_2014.05.
7 Related Documents
Screw Compressor J-series 7.1 Development View and Configuration Table of the Parts
7-19
Part
No.
Part name
280J
Type, etc.
Part code No. Quantity/unit
Explosion proo
f
Standard for Propane S M L
36 Housing, balance piston CS03600-J280 1
38-1
Thrust bearing assembly, male
rotor
7320BEAXT7DF CS03800-J280M 1
38-2
Thrust bearing assembly, female
rotor
7316BEAXT7DF CS03800-J220M 1
39-1 Locknut AN20 NG31-020 1
39-2 Locknut AN16 NG31-016 1
40-1 Lock washer AW20 NG32-020 1
40-2 Lock washer AW16 NG32-016 1
42-1
Thrust bearing alignment spacer,
male rotor
CS04200-J280M 1
42-2
Thrust bearing alignment spacer,
female rotor
CS04200-J220M 1
43-1 Thrust bearing gland, male rotor CS04300-J280M 1
43-2 Thrust bearing gland, female rotor CS04300-J280F 1
44-1 Thrust bearing gland spacer, male rotor CS04400-J280M 1
44-2 Thrust bearing gland spacer, female rotor CS04400-J280F 1
45 Hexagon head screw M16×65 NB111016-065 12
46 Conical spring washer
Hexagon head
screw M16
ND320-016 12
48 Retainer for oil seal CS04800-J280 1
49 O-ring JIS B 2401 G165 PAH81-165 PC12-165 1
50 Oil seal SA1J 95 120 13 CS05010-320VD 1
51 Seal cover 1
52-1 O-ring JIS B 2401 G165 PAH81-165 PC12-165 1
52-2 O-ring JIS B 2401 P14 PAH80-014 PC11-014 1
53 Hexagon socket head cap screw M12×40 NB35412-040 8
54
Unloader slide valve S 1
Unloader slide valve M 1
Unloader slide valve L 1
58 Hexagon socket head cap screw M10×40 NB35410-040 9
60 Unloader cylinder 1
61 Hexagon socket head cap screw M20×110 NB35420-110 2
62 Hexagon socket head cap screw M20×170 NB35420-170 6
63 O-ring JIS B2401 G260 PAH81-260 PC12-260 2
64 Unloader piston CS06400-J280 1
65 O-ring JIS B2401 P225 PAH80-225 PC11-225 2
66 Teflon cap seal SUNR-BE-225 CS06600-J280 2
67 Push rod, unloader slide valve CS06700-J280 1
68 Guide pin
PH01NG 6×16
BK
NE2506-016 1
69 Locknut AN09 NG31-009 1
70 Lock washer AW09 NG32-009 1
73 O-ring JIS B2401 P58 PAH80-058 PC11-058 1
74 Unloader cylinder cover 1
75 O-ring JIS B2401 G230 PAH81-230 PC12-230 1
76 Hexagon socket head cap screw M16×60 NB35416-060 8
77
Unloader indicator cam S CS07700-J280S 1
Unloader indicator cam M CS07700-J280M 1
Unloader indicator cam L CS07700-J280L 1
78 Ball bearing #6000 CS07800-200 1
79 Retaining ring C type external JISB2804 (S10) NG12-010 1
80 Bearing gland CS08000-200 1
81 Hexagon socket head cap screw M6×15 NB35406-015 3
82-1 O-ring JIS B2401 P10A PAH80-010A PC11-010A 2
82-2 O-ring JIS B2401 P16 PAH80-016 PC11-016 1
83 Retainer, O-ring CS08300-J170 1
84 Spacer, unloader cylinder cover CS08400-J170 1
91 Shaft key CS09100-J280 1
100
Mechanical seal assembly
(including 100-1 to 100-5)
CS10002-320EBS 1
