mycom J Series User Manual

2205B0JE-DA-J-N_2014.05.
7 Related Documents
Screw Compressor J-series 7.1 Development View and Configuration Table of the Parts
7-18
Table 7-3 Configuration table of the parts of 280J
Part
No.
Part name
280J
Type, etc.
Part code No. Quantity/unit
Explosion proo
f
Standard for Propane S M L
1
Main rotor casing S 1 — —
Main rotor casing M — 1 —
Main rotor casing L — — 1
2 Hexagon socket head cap screw M20×110 NB35420-110 40
3 Parallel pin
16 dia. ×110 with
female thread
NE2316-110A 4
4 Eyebolt M24 NB600-24 2
5 Suction cover 1
6 O-ring JIS B 2401 P580 PAH80-580 PC11-580 1
7 Eyebolt M36 NB600-36 2
9-1 O-ring JIS B 2401 P85 PAH80-085 PC11-085 1
9-2 Back-up ring for O-ring SUN-2BP 85 PBP21-085 2
10-A Plug R1/2 NF06-015 1
10-B Plug R3/4 NF06-020 1
10-C Plug R1/2 NF06-015 1
10-D Plug R1/2 NF06-015 1
10-E Plug R1/2 NF06-015 1
11 Bearing head 1
12 O-ring JIS B 2401 P580 PAH80-580 PC11-580 1
13 Eyebolt M36 NB600-36 1
14 Spring pin 4 dia.×10 NE3204-010 4
15-A Plug R1/2 NF06-015 1
15-B Plug R3/4 NF06-020 1
15-C Plug R1/2 NF06-015 1
15-D Plug R3/4 NF06-020 1
16 Bearing cover 1
17-1 O-ring JIS B 2401 P480 PAH80-480 PC11-480 1
17-2 O-ring JIS B 2401 P14 PAH80-014 PC11-014 1
18 Hexagon socket head cap screw M20×70 NB35420-070 16
19 Dowel pin
16 dia. ×70 with
female thread
NE2316-070 2
20 Spring pin 3 dia.×10 NE3203-010 1
21-A Plug R1/8 NF06-004 1
21-B Plug R1/4 NF06-008 1
21-C Plug R1/4 NF06-008 1
21-D Plug R3/8 NF06-010 1
21-E Plug R3/8 NF06-010 1
22 Balance piston cover 1
23-1 O-ring JIS B 2401 G190 PAH81-190 PC12-190 1
23-2 O-ring JIS B 2401 G150 PAH81-150 PC12-150 1
24 Hexagon socket head cap screw M20×70 NB35416-060 13
25
Male rotor S 1 — —
Male rotor M — 1 —
Male rotor L — — 1
26
Female rotor S 1 — —
Female rotor M — 1 —
Female rotor L — — 1
27 Bearing, male rotor Sleeve bearing CS02700-J280M 2
28 Bearing, female rotor Sleeve bearing CS02700-J220M 2
29-1 Retaining ring C type internal JIS B 2804 (H190) NG11-190 2
29-2 Retaining ring C type internal JIS B 2804 (H150) NG11-150 2
30 Balance piston 250*UD CS03000-J280 1
31 Key for balance piston 250*** CS03100-J280 1
32 Retaining ring C type external JIS B 2804 (S80) NG12-080 1
33 Sleeve, balance piston 250*UD CS03300-J280 1
34 Spring pin 6 dia.×12 NE3206-012 3 → 2
35-1 O-ring JIS B 2401 G150 PAH81-150 1
35-2 O-ring JIS B 2401 G190 PAH81-190 PC12-190 1
