2205B0JE-DA-J-N_2014.05.
2 Structure and Specifications of the Compressor
Screw Compressor J-series 2.3 Compressor Specifications
2-5
2.3.2 Operation Limits
Table 2-4 Operation Limits of the J-Series Screw Compressor
Item Limit value
Maximum discharge pressure MPa 3.2
Maximum suction pressure MPa 1.0
Minimum suction pressure MPa -0.080
Minimum lubrication pressure Po: Lubrication pressure, Ps: Suction pressure,
Pd: Discharge pressure
MPa ( Po - Ps ) ≧0.5
Forced oil supply system MPa ( Po - Pd ) ≧0.05
Differential pressure oil supply system MPa ( Pd - Po ) ≤ 0.15
Maximum suction temperature °C 50
Minimum suction temperature °C -60
Maximum discharge temperature °C 100
Maximum lubrication temperature °C 70 but, when using in the
explosion-proof area, it is 55.
Minimum lubrication temperature °C 20
Maximum rotation speed (M rotor) min
-1
4500 (280J: 3600)
Minimum rotation speed (M rotor) min
-1
1450
Refrigerant - NH
3
, HFC, CO
2
, Propane
and Propylene
Note 1: Pressure unit [MPa] in the table 2-4 means gauge pressure.
Note 2: The J-series compressors must be used within the allowable operation range defined in the
table 2-4 and next page, Figure2-1.
When using J series in the explosion-proof area, use certainly in the condition with the
maximum suction temperature of equal to or less than 50 °C, the maximum lubrication
temperature of equal to or less than 55 °C (Refer to Note).
It is important specifically in the Application limits each clause eyes.
Note: When exceeding 55 °C, consult us for the further study because the maximum
lubrication temperature limitation is related to the atmosphere temperature, too.
To Next Page
