mycom UD Series User Manual

Chapter 7 Related Documents
UD-series Screw Compressor 7.2 Parts Configuration Table 320*UD
7-24
Table 7-5 Parts Configuration Table of 320*UD models
P/N
Part Name
Code No.
Remarks
Q’ty.
1 Main Rotor Casing CS00100-320S 320S** 1(SUD)
1 Main Rotor Casing CS00100-320M 320M** 1(MUD)
1 Main Rotor Casing CS00100-320L 320L** 1(LUD)
1 Main Rotor Casing CS00100-320LL 320LL** 1 (LLUD)
2 Hexagon Socket Head Cap Screw NB35424-080 M24x80 52
3 Alignment Pin NE2025-080 φ25x80 4
4 Eye Bolt NB600-30 M30 2
5 Suction Cover CS00500-320U
320*** LLUD is
excluded
1
5 Suction Cover CS00500-320LL 320LL** 1 (LLUD)
6 Gasket, Suction Cover CS00600-320N 320*** 1
7 Eye Bolt NB600-16 M16 2
-
A
Plain Washer, Eye Bolt
ND710-016
M16×30
4
8
B
Spring Pin
NE3206-018
φ6×18
2
9
C
O-ring
PA11-058
JISB2401 1A P58
1
10
D
Plug
NF06-015
R1/2
1
10 H Plug NF06-020 R3/4 1
11
H
Bearing Head
CS01100-320DH
320***
1
（
*UD)
11
M
Bearing Head
CS01100-320DM
320***
1
（
*UD)
11
L
Bearing Head
CS01100-320DL
320***
1
（
*UD)
12
Gasket, Bearing Head
CS01200-320N
320***
1
13
Eye Bolt
NB600-16
M16
1
-
Plain Washer, Eye Bolt
ND710-016
M16×30
2
14
Spring Pin
NE3206-018
φ6x18
2
15
Plug
NF06-008
R1/4
3
16
Bearing Cover
CS01600-320D
320***
1
（
*UD)
17
1
Gasket, Bearing Cover
CS01700-320DN
320***
1
（
*UD)
18 Hexagon Socket Head Cap Screw
NB35420-070
M20x70
20(*UD)
18 Hexagon Socket Head Cap Screw NB35420-120 M20x120 14(*UD)
19 Alignment Pin
NE2016-070
φ16x70
2
20 Spring Pin NE3203-016 φ3×16 1
21 Plug NF06-010 R3/8 1
22 Balance Piston Cover CS02200-320 320*** 1
23 Gasket, Balance Piston Cover CS02300-320N 320*** 1
24 Hexagon Socket Head Cap Screw NB35416-045 M16x45 11
25 Male Rotor
CS02520-320S 320S** O-profile 1(SUD)
26 Female Rotor
25 Male Rotor
CS02520-320M 320M** O-profile 1(MUD)
26 Female Rotor
25 Male Rotor
CS02520-320L 320L** O-profile 1(LUD)
26 Female Rotor
25 Male Rotor
- 320LL** O-profile 1 (LLUD)
26 Female Rotor
27 Main Bearing CS02700-320N 320*** O-ring type
"2 (*UD)
4 (LLUD)
28 Side Bearing CS02800-320N 320*** O-ring type 2 (*UD)
29 Stop Ring NG11-200 H200
4
