mycom UD Series User Manual

Chapter 7 Related Documents
UD-series Screw Compressor 7.2 Parts Configuration Table 320*UD
7-25
P/N
Part Name
Code No.
Remarks
Q’ty.
30 Balance Piston CS03000-320 320*** 1
31 Key, Balance Piston CS03100-320 320*** 1
32 Stop Ring NG12-100 S100 1
33 Sleeve, Balance Piston CS03300-320 320*** 1
34
Spring Pin
NE3206-014
φ6x14
1
35 O-ring PA12-190 JISB2401 1A G190 1
36 Spacer CS03600-320 320*** 1
37 Stop Ring NG11-200 H200 2
38 Thrust Bearing CS03800-320 7321A 2
39 Lock Nut NG31-021 AN21 2
40 Lock Washer NG32-021 AW21 2
42 Spacer, Thrust Bearing Alignment CS04200-320 320*** 2
43 Thrust Bearing Gland CS04300-320 320*** 2
45 Hexagon Head Bolt NB15520-055 M20X55 8
46 Lock Washer ND150-020 320*** 8
46
H
E
Lock Washer Set (old , plate type) CS0469-G
320*** 8pｓ/set
-
48 Retainer, Oil Seal CS04800-320VDS
320V** BBS
Ⅲ
BBSE BOS
1
48 Retainer, Oil Seal CS04800-320
320*** UV-4 BBS
Ⅰ
He
-
49 L O-ring PA12-160 JISB2401 1A G160 1
50 M Oil Seal CS05010-320VD SA1J95X120X13 1
51 H Seal Cover CS051000-320BBS 320*** 1
51 Seal Cover CS051000-320UV4 320*** (UV4) 1
51 L Seal Cover CS05100-320HE 320*** (HE) -
52 M Gasket, Seal Cover CS05200-320N 320*** 1
53 H Hexagon Socket Head Cap Screw NB35416-040 M16X40 8
54,5
5
L Unloader Slide Valve Assembly L Port CS05400-320SDL 320S** 1 (SUD)
54,5
5
M Unloader Slide Valve Assembly M Port CS05400-320SDM 320S** 1 (SUD)
54,5
5
H Unloader Slide Valve Assembly H Port CS05400-320SDH 320S** 1 (SUD)
54,5
5
L Unloader Slide Valve Assembly L Port CS05400-320MDL 320M** 1 (MUD)
54,5
5
M Unloader Slide Valve Assembly M Port CS05400-320MDM 320M** 1 (MUD)
54,5
5
H Unloader Slide Valve Assembly H Port CS05400-320MDH 320M** 1 (MUD)
54,5
5
L Unloader Slide Valve Assembly L Port CS05400-320LDL 320L** 1 (LUD)
54,5
5
M Unloader Slide Valve Assembly M Port CS05400-320LDM 320L** 1 (LUD)
54,5
5
H Unloader Slide Valve Assembly H Port CS05400-320LDH 320L** 1 (LUD)
54,5
5
L Unloader Slide Valve Assembly L Port CS05404-320LLDL
54,5
5
M Unloader Slide Valve Assembly M Port CS05404-320LLDM
54,5
5
H Unloader Slide Valve Assembly L Port CS05404-320LLDH
54,
55
Unloader Slide Valve Assembly L Port CS05404-320LLUL 320LL** 1 (LLUD)
54,
55
Unloader Slide Valve Assembly M Port CS05404-320LLUM 320LL** 1 (LLUD)
54,
55
Unloader Slide Valve Assembly H Port CS05404-320LLUH 320LL** 1 (LLUD)
