Chapter 7 Related Documents
UD-series Screw Compressor 7.2 Parts Configuration Table 320*UD
7-26
58
Hexagon Socket Head Cap Screw NB35416-050 M16X50 4
59
O-ring PA11-032 JISB2401 1A P32 1
60
Unloader Cylinder CS06000-320S 320S** 1 (SUD)
60
Unloader Cylinder CS06000-320M 320M** 1 (MUD)
60
Unloader Cylinder CS06000-320L 320L** 1 (LUD)
60
Unloader Cylinder CS06000-320LL 320LL** 1 (LLUD)
61
Hexagon Socket Head Cap Screw NB35420-050 M20X50 2
62
Hexagon Socket Head Cap Screw NB35420-110 M20X110 6
63
O-ring PA12-240 JISB2401 1A G240 1
64
Unloader Piston CS06400-320S 320*** 1
65
O-ring PA11-200 JISB2401 1A P200 1
66
Cap Seal CS06600-320 CAP-3BE200 1
67
Push Rod, Unloader Slide Valve CS0670-GS 320S** 1 (SUD)
67
Push Rod, Unloader Slide Valve CS0670-GM 320M** 1 (MUD)
67
Push Rod, Unloader Slide Valve CS0670-GL 320L** 1 (LUD)
67
Push Rod, Unloader Slide Valve CS06709-320LL 320LL** 1 (LLUD)
68
Guide Pin NE2506-016 φ6x16 1
69
Lock Nut NG31-010 AN10 1
70
Lock Washer NG32-010 AW10 1
71
Lock Nut NG31-012 AN12 1
72
Lock Washer NG32-012 AW12 1
73
O-ring PA11-044 JISB2401 1A P44 1
74
Unloader Cylinder Cover CS07400-320 320*** 1
75
O-ring PA12-210 JISB2401 1A G210 1
76
Hexagon Socket Head Cap Screw NB35416-040 M16X40 8
77
Indicator Cam CS07700-320S 320S** 1 (SUD)
77
Indicator Cam CS07700-320M 320M** 1 (MUD)
77
Indicator Cam CS07700-320LL 320LL** 1 (LLUD)
78
Ball Bearing CS07800-200 #6000 1
79
Stop Ring NG12-010 S10 1
80
Bearing Gland CS08000-200 200L** 1
81
Hexagon Socket Head Cap Screw NB35406-015 M6×15 3
82
V-ring CS08200-200B VH10 NBR 1
82
V-ring CS08200-200V VH10 FPM -
83
Spring CS08300-200 200L** 1
84
Retainer, Indicator Cam Spring CS08400-200 200L** 1
85
Oil Injection Pipe CS08500-320SU 320S** 1 (SUD)
85
Oil Injection Pipe CS08500-320MU 320M** 1 (MUD)
85
Oil Injection Pipe CS08500-320LU 320L** 1 (L*UD)
86
O-ring PA12-030 JISB2401 1A G30 1
Guide Block Assembly CS08700-320 320*** 1
89
O-ring PA11-024 JISB2401 1A P24 2
91
Shaft Key CS09100-320 320*** 1
92
Suction Flange without hole CS71400-P350 MYK350A(14") Male 1
93
Gasket, Suction Flange CS09300-320N MYK350A 1
To Next Page
