5. BROWSING THE MENU
4. DEFAULT SETTINGS
LThe control panel is supplied with a DEFAULT SETTINGS:
working time, slow down and automatic closing for a standard gate.
To reload the DEFAULT SETTINGS:
- Press BREAK to cut the power OFF and to turn it ON
- Turn SENS to the maximum (+) and POWER to half position
5.1 FUNCTIONS MENU
5.1.1 AUTOMATIC CLOSINGA
The AUTOMATIC CLOSING DEFAULT is set at 3 sec.
To set the AUTOMATIC CLOSING TIME:
- Press SET for 3 sec. DL1 blinks, release SET.
- Press BREAK and release.
- The blinker and led DL1 light up, the control panel starts the count down.
- Press BREAK again when reached the desired time, the blinker turns off.
The time has been set (automatic closing time max. 120 sec.).
To desactivate the AUTOMATIC CLOSING:
- Press SET for 3 sec. and release, the led DL1 blinks.
- Press BREAK and hold for 5 sec., the AUTOMATIC CLOSING has been deactivated.
5.1.2 8K2 RESISTIVE SAFETY EDGE INPUT (cut the power off)
To activate the 8K2 input as safety in opening and closing press SET + SET TX and turn the control panel on.
SET
Use SET:
- To programm the control panel (section 8.1. AUTOMATIC MODE – 8.2. SEQUENTIAL MODE).
- To activate or desactivate the automatic closing (section 5.1.1)
SET TX
Use SET TX:
- To store or to delete a radio code.
WORK
Use WORK:
- As START command
- For SEQUENTIAL PROGRAMMING
BREAK
Use BREAK:
- To activate and set the AUTOMATIC CLOSING TIME (section 5.1.1)
