8. PROGRAMMING
The control panel is supplied with a SEQUENTIAL PROGRAMMING DEFAULT (obstacle detection excluded)
ATTENTION:
Before starting PROGRAMMING make sure mechanical ground stops have been properly fitted.
8.1 AUTOMATIC mode
8.1.1 AUTOMATIC mode with OBSTACLE DETECTION
ATTENTION!:
Before proceeding to programming, start a functional cycle test to proof the motor’s thrust.
The thrust has to be proper to the gate weight no matters if light or heavy gates.
If adjustments are needed, regulate POWER so that the gate doesn’t stop opposing a light contrast pressure.
• Start programming with cool operator.
• The AUTOMATIC MODE PROGRAMMING can only perform if mechanical ground endstops are fitted,
in Opening and Closing
- Gate in CLOSING POSITION.
- SENS in half position.
- If during programming the gates stop before reaching the ground endstops, turn SENS (sensitivity) clockwise (to +).
- Press SET and keep pressed for 10 sec., DL1 starts blinking.
- When motor starts working release SET.
- Motor runs firstly a FULL OPENING till reaching the limit switch in opening.
Then it starts CLOSING till reaching the closing limit switch.
- When the procedure is finished, all time settings are saved.
The control panel is now ready for normal operation.
ATTENTION!:
Check the proper GATE OPERATION SENSITIVITY.
If adjustments are needed, turn SENS clockwise (to +) and regulate accordingly.
The sensitivity has to be proper in order to prevent uncorrect operation.
OBSTACLE DETECTION OPERATION
- If an obstacle is detected in opening, the gate stops and reverses for 10 cm.
- The gate starts closing automatically after 30 sec., and this will be for 3 attempts.
If the area still remains unclear the gate stays open.
- If an obstacle is detected in closing, the gate stops and reverses till fully open.
- The gate starts closing automatically after 30 sec., and this will be for 3 attempts.
If the area still remains unclear the gate stays open.
