14
Q81S_09_2021
PROTECO S.r.l. Via Neive, 77 - 12050 Castagnito (CN) ITALY Tel. +39 0173 210111 - Fax +39 0173 210199 info@proteco.net - www.proteco.net
7. LOADING RADIO CODESO
The control panel DOESN’T ALLOW TO LOAD any remote control if SAFETY DEVICES are DISCONNECTE.
Make sure inputs no. 2 STOP (DL5), no. 5 photocell in CLOSING (DL7), no. 6 photocell in OPENING (DL8) and no. 23
SAFETY EDGE IN CLOSING (DL3), are connected.
LED OFF = input DEACTIVATED
LED ON = input ACTIVATED
If no safety device has been wired, proceed to bridge temporarily the terminal according to chapter 3.6.1.
The control panel has been designed to operate with fixed code or rolling-code remote controls.
Choose the remote control you wish to store carefully: once the remote control has been loaded and memorized,
the control panel shall only recognize that kind of radio code without possibility of reset.
Before starting proceed to delete all existing radio codes.
7.1 DELETING EXISTING RADIO CODES
- Press SET-TX and keep pressed for 10 seconds (DL1 blinks).
- DL1 turns off. All codes have been deleted.
7.2 LOADING A REMOTE CONTROL AS START COMMAND
- Press SET-TX once: DL1 blinks (1 blink – stop – 1 blink ….)
- Load within 5 sec. the remote control you wish to store.
The control panel has stored the radio code and goes out the programming automatically.
It is possible to load until 32 different radio codes (Start + Pedestrian + 2° radio channel).
7.3 LOADING A REMOTE CONTROL AS PEDESTRIAN COMMAND
- Press SET-TX twice. DL1 blinks (2 blinks – stop – 2 blinks ….)
- Load within 5 sec. the remote control you wish to store.
The control panel has stored the radio code and goes out the programming automatically.
7.4 LOADING A REMOTE CONTROL AS 2° RADIO CHANNEL COMMAND (MRX01 jack)
- Press SET-TX three times. DL1 blinks (3 blinks – stop – 3 blinks ….)
- Load within 5 sec. the remote control you wish to store.
The control panel has stored the radio code and goes out the programming automatically.
